STANDARD FINE CERAMICS


electric furnace (max 1700℃）



wire covered ceramics

name size material
ΦＡ ΦＢ Ｃ 約Ｄ
GAS-1 3.2±0.15 1.4±0.15 3.2±0.2 0.5 steatite
GAS-2 4.2±0.15 1.7±0.15 4.2±0.2 0.6
GAS-3 5.1±0.2 2.2±0.15 5.1±0.2 0.8
GAS-4 6.7±0.2 2.9±0.2 6.7±0.2 1.3
GAS-5 8.2±0.2 3.6±0.2 8.2±0.2 1.6
GAS-6 10.1±0.2 3.9±0.2 10.1±0.2 2
GAS-7 11.1±0.2 4.4±0.2 11.1±0.2 2.4
GAS-8 12.7±0.25 5.5±0.2 12.7±0.25 2.6
GAS-9 12.7±0.25 6.4±0.2 12.7±0.25 2.6
GA-1 2.0±0.2 0.75±0.15 2.0±0.2 0.4 aluminum
GA-2 2.5±0.2 1.2±0.15 2.5±0.2 0.6
GA-3 5.0±0.2 2.0±0.15 5.0±0.2 1.6
GA-4 5.0±0.2 2.5+0.3 5.0±0.2 1.6
GA-5 6.6±0.3 3.8±0.2 6.4±0.3 1.2


bushing ceramics

name size memo name size memo
ΦＡ ΦＢ ΦＣ ｔ Ｌ ΦＡ ΦＢ ΦＣ ｔ Ｌ
BS-64313-05 6 4 3 3 0.5 M3 BS-97513-05 9 7 5 3 0.5 M5
BS-64313-10 1.0 BS-97513-10 1.0
BS-85313-05 8 5 3 3 0.5 M3 BS-97513-15 1.5
BS-85313-10 1.0 BS-97513-20 2.0
BS-85313-15 1.5 BS-97513-25 2.5
BS-85313-20 2.0 BS-97513-30 3.0
BS-85313-25 2.5 BS-127513-05 12 7 5 3 0.5 M5
BS-85313-30 3.0 BS-127513-10 1.0
BS-105313-05 10 5 3 3 0.5 M3 BS-127513-15 1.5
BS-105313-10 1.0 BS-127513-20 2.0
BS-105313-15 1.5 BS-127513-25 2.5
BS-105313-20 2.0 BS-127513-30 3.0
BS-105313-25 2.5 BS-138613-10 13 8 6 3 1.0 M6
BS-105313-30 3.0 BS-138613-15 1.5
BS-75413-05 7 5 4 3 1.5 M4 BS-138613-20 2.0
BS-75413-10 1.0 BS-138613-30 3.0
BS-86413-05 8 6 4 3 0.5 M4 BS-1510613-10 15 10 6 3 1.0 M6
BS-86413-10 1.0 BS-1510613-15 1.5
BS-86413-15 1.5 BS-1510613-20 2.0
BS-86413-20 2.0 BS-1510613-30 3.0
BS-86413-25 2.5 BS-1510613-40 4.0
BS-86413-30 3.0 BS-1510613-50 5.0
material: aluminum


washer ceramics

3_2
name size material memo
ΦＡ ΦＢ Ｃ
WS-5028-10 5.0 2.8 1.0 aluminum M2
WS-5028-15 1.5
WS-5028-20 2.0
WS-6033-10 6.0 3.3 1.0 aluminum M3
WS-6033-15 1.5
WS-6033-20 2.0
WS-8043-10 8.0 4.3 1.0 aluminum M4
WS-8043-15 1.5
WS-8043-20 2.0
WS-1053-10 10.0 5.3 1.0 aluminum M5
WS-1053-15 1.5
WS-1053-20 2.0
WS-1063-10 10.0 6.3 1.0 aluminum M6
WS-1063-15 1.5
WS-1063-20 2.0


SCREW type BOLT ceramics
type screw Φ material gas escape hole
Ｄ Ｈ Ｌ
RAT-3-5 5.5 2.0 5 M3 P=0.5 AL2O3
RAT-3-6 6
RAT-3-8 8 not exist
RAT-3-10 10
RAT-4-6 7 2.6 6 M4 P=0.7 AL2O3
RAT-4-8 8
RAT-4-10 10 exist
RAT-4-12 12
RAT-5-8 9 3.3 8 M5 P=0.8 Al2O3
RAT-5-10 10
RAT-5-12 12 exist
RAT-5-15 15



BOLT ceramics

name size screw material
Ｄ Ｈ Ｌ
BT-5-8 8 3.5 8 M5
P=0.8		 aluminum
BT-5-10 10
BT-5-12 12
BT-5-15 15
BT-5-18 18
BT-5-20 20
BT-6-10 10 4.0 10 M6
P=1.0		 aluminum
BT-6-12 12
BT-6-15 15
BT-6-18 18
BT-6-20 20
BT-6-25 25
BT-8-12 13 5.5 12 M8
P=1.25		 aluminum
BT-8-15 15
BT-8-18 18
BT-8-20 20
BT-8-25 25
BT-8-30 30

NUT ceramics
name size screw material
Ｄ Ｈ
NT-3-24 5.5 2.4 M3
P=0.5		 aluminum
NT-4-32 7.0 3.2 M4
P=0.7
NT-5-40 8.0 4.0 M5
P=0.8
NT-6-50 10 5.0 M6
P=1.0
NT-8-65 13 6.5 M8
P=1.25


SPACER ceramics

3_9
name size memo name size memo
ΦＡ ΦＢ Ｌ ΦＡ ΦＢ Ｌ
CR-5028-3 5±0.1 3±0.1 M2.6 CR-1053-3 10±0.2 3±0.1 M5
CR-6028-4 4±0.1 CR-1053-4 4±0.1
CR-5028-5 5±0.1 CR-1053-5 5±0.1
CR-5028-6 2.8 ＋0.2 6±0.2 CR-1053-6 6±0.2
CR-5028-7 -0.15 7±0.2 CR-1053-7 5.3 ＋0.2 7±0.2
CR-5028-8 8±0.2 CR-1053-8 -0.15 8±0.2
CR-5028-9 9±0.2 CR-1053-9 9±0.2
CR-5028-10 10±0.2 CR-1053-10 10±0.2
CR-6033-3 6±0.2 3±0.1 M3 CR-1053-12 12±0.2
CR-6033-4 4±0.1 CR-1053-15 15±0.2
CR-6033-5 5±0.1 CR-1063-3 10±0.2 3±0.1 M6
CR-6033-6 6±0.2 CR-1063-4 4±0.1
CR-6033-7 3.3 ＋0.2 7±0.2 CR-1063-5 5±0.1
CR-6033-8 -0.15 8±0.2 CR-1063-6 6±0.2
CR-6033-9 9±0.2 CR-1063-7 6.3 ＋0.2 7±0.2
CR-6033-10 10±0.2 CR-1063-8 -0.15 8±0.2
CR-6033-12 12±0.2 CR-1063-9 9±0.2
CR-6033-15 15±0.2 CR-1063-10 10±0.2
CR-8043-3 8±0.2 3±0.1 M4 CR-1063-12 12±0.2
CR-8043-4 4±0.1 CR-1063-15 15±0.2
CR-8043-5 5±0.1 material: aluminum
CR-8043-6 6±0.2
CR-8043-7 4.3 +0.2 7±0.2
CR-8043-8 -0.15 8±0.2
CR-8043-9 9±0.2
CR-8043-10 10±0.2
CR-8043-11 11±0.2
CR-8043-12 12±0.2
材質：アルミナ
